Thread: Glock trigger guard undercut.

  1. #1
    Join Date
    Nov 2008
    Location
    Northern Virginia
    Posts
    622
    Feedback Score
    48 (100%)

    Glock trigger guard undercut.

    I need to get the trigger guard on my glock 19 undercut. Who would you guys recommend ?

    The only place that would do it nearby is going to cost $150. I also need the mag release on the gun trimmed down a little bit too because it is a gen 4 and the mag release button is huge.

  2. #2
    Join Date
    Jan 2011
    Location
    South Texas
    Posts
    1,566
    Feedback Score
    30 (97%)
    It's just plastic.

    Sharpen your pocket knife and whittle off what you don't want, then clean it up with some emory cloth.

  3. #3
    Join Date
    May 2010
    Location
    Detroit Rock City
    Posts
    883
    Feedback Score
    1 (100%)
    Pocket knife? What is this, the 1880s? Just kidding, bro.

    Option 1) Get a Dremel aka the Wonder Tool (ok, only I call it that). You can use the grinding stone to do this. Put it on low and go slow!

    Option 2) Or for better results but more time consuming, pick out a round wooden dowel close to the radius you want. Put the frame in a vice, wrap the dowel in some sandpaper, and slowly go back and forth keeping the dowel even.

    For either Option 1 or 2, use a buffing wheel on the Dremel, or some emery cloth if you don't have one, and polish it up. If you use the Dremel, do NOT stay in one area too long. Cranking the RPMs up is fine, but if you stay in one area too long - the frame will begin to melt from the friction. And it's a bitch to clean it up nice once it's melted.

    If you buy a Dremel, get the corded version with micro adjustable RPMs. The cordless, macro adjustable RPM version is a turd.

    Hope this helps.

  4. #4
    Join Date
    May 2009
    Location
    Corpus Christi, Texas
    Posts
    2,251
    Feedback Score
    7 (100%)
    To get it to look its best, use a Dremel sanding wheel. Once you get it close to where you want it, use a buffing wheel with a little compound. Be careful to go at a slower speed. If it heats up to much due to friction, out of nowhere you'll take out much more than intended.

    Here's one of the M&Ps I've done.



    This is a different one where I rounded the sides a bit more and didn't cut it out as much. Sorry these are M&Ps, but I'm content with my Glocks. $150 for just undercutting the trigger guard is a bit much, it's not a 1911.

    Last edited by jonconsiglio; 03-20-12 at 22:33.
    Proven combat techniques may not be flashy and may require a bit more physical effort on the part of the shooter. Further, they may not win competition matches, but they will help ensure your survival in a shooting or gunfight on the street. ~ Paul Howe

  5. #5
    Join Date
    Nov 2008
    Location
    Northern Virginia
    Posts
    622
    Feedback Score
    48 (100%)
    The dremel option is intimidating. I have never used one on plastic before.

    I think I can make it work for the mag release pretty easily.

  6. #6
    Join Date
    May 2010
    Posts
    365
    Feedback Score
    0
    No reason to be intimidated. You totally control the speed and pressure. You can hover it just away from the nylon and not take off anything, then gently work it in to barely scrape the surface.

    It's pretty funny, when doing it to remove the Gen 3 finger grooves a few months ago (I used the sanding drum), I got it warm enough to smell the nylon - smells exactly like 550 cord. Hilarious.

    [[Link]] to absolute most basic dremeling (removal of grooves). I'll clean it up and probably add stippling at some point.
    Last edited by CumbiaDude; 03-20-12 at 23:54.

  7. #7
    Join Date
    Nov 2009
    Location
    Wide Open Spaces
    Posts
    247
    Feedback Score
    22 (96%)
    I use a 1/2" wooden dowel with 80 grit sand paper wrapped around it. Once I have it close, I switch to 120 grit, then 220. After that I use a buffing wheel on my dremel to finish it up. You could stick with the dowel, as I did in the past, just keep going to less course grits, like 600, etc. The first 3 Glocks I did was with just the dowel and they turned out really well.

  8. #8
    Join Date
    Nov 2010
    Posts
    918
    Feedback Score
    3 (100%)
    I undercut the guard and cut the finger grooves off of my G19 with a rasp that I got in a hardware store for 10 bucks. I fired a few rounds, locked/cleared/field stripped, then used the coarse side to quickly remove the offending parts. Lather, rinse, repeat until I got it just the way I wanted it. Then I used the fine side to smooth it up a little.

    My crude methods have another benefit. There's a guy at my range who's just gotta comment on things that he knows almost nothing about. He was watching over my shoulder as I shot and was about to say something about my group until I attacked my G19 with the rasp. As he looked on in horror, I said, "Hey, it's not like it's a 1911."

    He hasn't spoken to me since.

    YMMV.


    Okie John
    Quote Originally Posted by Suwannee Tim View Post
    He wants something par-full. But not too par-full.

  9. #9
    Join Date
    Oct 2006
    Posts
    789
    Feedback Score
    11 (100%)
    I would be real careful with a Dremel on a plastic gun. It takes material away fast. For a first timer, I would go with the dowel and sand paper idea first. I use Phillips screw drivers with some 180 grit or so wrapped around the shaft of the driver. When you've got it about where you want it use a BBQ lighter to gently scorch the area. This will burn down all of the fuzzies sticking up. Then wipe the soot off with a towel and you should be good to go.

  10. #10
    Join Date
    Dec 2010
    Location
    Coeur d'Alene, ID
    Posts
    439
    Feedback Score
    1 (100%)
    Quote Originally Posted by og556 View Post
    I need to get the trigger guard on my glock 19 undercut. Who would you guys recommend ?
    Do you want this done to alleviate "glock knuckle" or to get a higher grip on the gun?
    "The strongest reason for the people to retain the right to keep and bear arms is, as a last resort, to protect themselves against tyranny in government." - Thomas Jefferson

  11. #11
    Join Date
    Nov 2008
    Location
    Northern Virginia
    Posts
    622
    Feedback Score
    48 (100%)
    I would like to alleviate glock knuckle. My middle finger is sore after shooting the compact glocks.

    My middle finger on my right hand is pretty beat up from an injury from years ago and it still hurts after shooting the glock for a while. The finger swells at the joint sometimes after long shooting sessions with a compact glock because its right against the trigger guard.

  12. #12
    Join Date
    Aug 2006
    Location
    Kansas
    Posts
    1,048
    Feedback Score
    34 (100%)
    Did the undercut to the four Glocks I have here now and it made an amazing difference in comfort on the middle finger. I also get rid of the finger grooves as well.

    It's well worth it.
    "Colts and Kimbers are what you show your friends. Glocks and HK's are what you show your enemies."

    Sig Sauer LE Armorer
    Glock LE Armorer
    Colt AR15/M16 Armorer
    T.O.S.S. (Tactical Officer Survival School) inst. Tom Long
    Vicker's Tactical Pistol 1 & 2 Carbine 1 Advanced carbine Inst. Larry Vickers
    Intermediate pistol Inst. Ken Hackathorn
    Combat Speed Inst. Dave Harrington
    Performance Pistol Inst. Frank Proctor

  13. #13
    Join Date
    Dec 2010
    Posts
    213
    Feedback Score
    0
    The undercut has made a big difference with my G21SF.

    BE AN ORGAN DONOR.
    You can give the gift of life to as many as 50 people!
    It takes less than 3 minutes to register.
    Go to: http://donatelife.net/register-now/

  14. #14
    Join Date
    Aug 2006
    Location
    Kansas
    Posts
    1,048
    Feedback Score
    34 (100%)
    Really impressed with that rounding of the trigger guard. That's the one thing I've not yet attempted.
    "Colts and Kimbers are what you show your friends. Glocks and HK's are what you show your enemies."

    Sig Sauer LE Armorer
    Glock LE Armorer
    Colt AR15/M16 Armorer
    T.O.S.S. (Tactical Officer Survival School) inst. Tom Long
    Vicker's Tactical Pistol 1 & 2 Carbine 1 Advanced carbine Inst. Larry Vickers
    Intermediate pistol Inst. Ken Hackathorn
    Combat Speed Inst. Dave Harrington
    Performance Pistol Inst. Frank Proctor

  15. #15
    Join Date
    Dec 2010
    Location
    Coeur d'Alene, ID
    Posts
    439
    Feedback Score
    1 (100%)
    Quote Originally Posted by og556 View Post
    I would like to alleviate glock knuckle
    In that case you may want to consider just flattening out the sharp corner of the trigger guard on the spot that hits your knuckle. That's what I did, and it feels great.
    "The strongest reason for the people to retain the right to keep and bear arms is, as a last resort, to protect themselves against tyranny in government." - Thomas Jefferson

  16. #16
    Join Date
    Jan 2011
    Posts
    570
    Feedback Score
    1 (100%)
    Quote Originally Posted by Hayden Billick View Post
    In that case you may want to consider just flattening out the sharp corner of the trigger guard on the spot that hits your knuckle. That's what I did, and it feels great.
    Big +1, another here that did this. 5 minutes with a couple files gave me a significantly better feeling Glock. Let me know if youd like a picture of what Hayden has described.

  17. #17
    Join Date
    Jul 2009
    Location
    Arizona
    Posts
    1,285
    Feedback Score
    44 (100%)
    Like some others have posted, if it's your first time, stay away from the Dremel.

    I started with 120 grit 3M "Sand Blaster" sandpaper (the purple colored stuff at Home Depot/Lowes that is anti-clog) wrapped around the cylindrical shaft of a ball point pen. Slowly knock down that protrusion and re-test your grip constantly. Then use some 600 grit and 1500 grit to really smooth things out.

    I've done many of these now and always begin with a Dremel, but only because I know what endpoint I'm trying to reach. I still use the 120 grit sandpaper wrapped on the pen to achieve a uniformly level surface because, oftentimes, dremeling leaves ripples, especially if you're removing a lot of material.
    Last edited by uwe1; 03-22-12 at 01:35.

  18. #18
    Join Date
    Dec 2010
    Posts
    213
    Feedback Score
    0
    Quote Originally Posted by one View Post
    Really impressed with that rounding of the trigger guard. That's the one thing I've not yet attempted.
    I have a tutorial with pictures for the rounding process. PM your email address and I'll send it to you. It's not difficult.
    BE AN ORGAN DONOR.
    You can give the gift of life to as many as 50 people!
    It takes less than 3 minutes to register.
    Go to: http://donatelife.net/register-now/

  19. #19
    Join Date
    Aug 2006
    Location
    Kansas
    Posts
    1,048
    Feedback Score
    34 (100%)
    Absolutely.

    Thanks.
    "Colts and Kimbers are what you show your friends. Glocks and HK's are what you show your enemies."

    Sig Sauer LE Armorer
    Glock LE Armorer
    Colt AR15/M16 Armorer
    T.O.S.S. (Tactical Officer Survival School) inst. Tom Long
    Vicker's Tactical Pistol 1 & 2 Carbine 1 Advanced carbine Inst. Larry Vickers
    Intermediate pistol Inst. Ken Hackathorn
    Combat Speed Inst. Dave Harrington
    Performance Pistol Inst. Frank Proctor

  20. #20
    Join Date
    Dec 2011
    Location
    O'ahu
    Posts
    2,832
    Feedback Score
    36 (100%)
    Quote Originally Posted by og556 View Post
    I need to get the trigger guard on my glock 19 undercut. Who would you guys recommend ?

    The only place that would do it nearby is going to cost $150. I also need the mag release on the gun trimmed down a little bit too because it is a gen 4 and the mag release button is huge.
    You're talking about Hatfield's huh? FWIW the $150 includes:

    Includes any combination of: undercutting trigger guard, at-ready cut, finger groove removal, grip reduction, any area of grip stippled including forward portion for "gamer" grip and two magazine floorplates.

    Though that still might be a little high? Idk, but I wanted them to do mine eventually, along with the rest of their Vanguard package. Now I may just have some things done a la cart, but still.
    Sic semper tyrannis.
