Thread: Preload & bottomed out data needed.

  1. #1
    Join Date
    Sep 2015
    Posts
    176
    Feedback Score
    1 (100%)

    Preload & bottomed out data needed.

    I researched across interweb for the data on various buffer spring in their respective receiver extensions and I found shockingly that not one forum have pinned thread with all springs' s specs. There's shockingly lack of data on this subject overall and I set out to change that with help of m4c community.

    I attempted to find all information I seek myself by using limited data I found and math gymnastics. I come to those numbers below which I doubt all are accurate within half pound. I would like for owners of those system to confirm if those data are accurate within half of pound or correct me please. You can find out easily by compressing your spring and buffer until its lick under the length of respective appropriate buffer tube that it goes in on scale calibrated for the weight of clear tube or pvc plus spring and buffer and note the weight. After finding preload that was you then fully compress it until buffer bottom out if your scale can handle it and note the weight. If your scale cant handle the weight then you could even work around the issue by tying say 15LB dumbell to charging handle in manner dumbell would be dangling vertically able to stand on its bottom if landed on flat surface. You then slowly place dumbell upright on ground and lift rifle muzzle up and slowly land put dangling dumbell on scale until the bcg start move forward and note the weight. Then subtract the scale reading with actual weight of 15LB dumbbell which might not be 15LB. Or stand on different scale weighting yourself and have somebody bottom out the buffer on scale that you are standing on then subtract the result with your weight.

    (For the rifle spring in A5 I did some failed spring engineering calculation and using believed to be botched result which I keep doubting so I average it with basic parabola of rifle spring in rifle tube using three known points of relaxed length at 12.75 inch and zero force then 10inch with 5.61lb of force then roughly 4.8inch with force of 10.9LB )

    I do not have anything but carbine tube, red springco, and carbine spring.

    Original rifle spring in rifle tube
    5.61 LB preload - 10.9 LB buffer bottom out

    Original rifle spring in A5 tube
    7.84 LB preload - 10.9 LB buffer bottom out
    It just might be close to 7.21LB if spring calculation I did was right.

    Green springco in A5 tube
    Unknown but wild estimate is
    8.5LB preload - 11LB buffer bottom out

    Red springco in carbine tube after about 5k round
    8.31LB preload - 11.22LB buffer bottom out

    Original carbine spring in carbine tube
    6.3LB preload - 11LB buffer bottom out

    This information would not be only useful for me but others looking into getting springco green to replace their rifle spring or red springco to replace their original carbine spring or even other spring that somebody may post data for.

    Other data for springco colors such as blue, white, etc. Is of course welcomed too. Other data for spring such as some flatwire springs or other high quality buffer spring will also be highly appreciated by rest of forum and me.

    Please continue to find and post your data desipte that you may see such data already exist ITT your data will give more accurate averaging and reinforce our finding. Please include round count for the spring data and say whats error margin for the round count of spring. Error margin from few hundred to thousand is much better than completely unknown.
    Last edited by SmugPePe; 11-21-16 at 01:38. Reason: Making the post more clear.

  2. #2
    Join Date
    Oct 2012
    Location
    Texas
    Posts
    1,929
    Feedback Score
    45 (100%)
    To educate a man in mind and not in morals is to educate a menace to society. --Theodore Roosevelt--

  3. #3
    Join Date
    Oct 2013
    Location
    North TX
    Posts
    1,457
    Feedback Score
    9 (100%)

  4. #4
    Join Date
    Oct 2012
    Location
    Midwest
    Posts
    5,155
    Feedback Score
    1 (100%)
    Quote Originally Posted by JSantoro View Post
    Stop dicking the dog, please. It's gross.

  5. #5
    Join Date
    Dec 2008
    Location
    Colorado
    Posts
    360
    Feedback Score
    0
    Quote Originally Posted by Ryno12 View Post
    Now that one's special...
    "Guns are like neurosurgeons. When you need one, you need one badly."

  6. #6
    Join Date
    Apr 2015
    Posts
    2,287
    Feedback Score
    0
    Mods be like....




    Sent from my iPhone using Tapatalk

  7. #7
    Join Date
    Nov 2012
    Location
    Rockledge, FL
    Posts
    425
    Feedback Score
    10 (100%)
    where is that forest whitaker meme when you need it?
    NRA Chief Range Safety Officer
    NRA Pistol, Rifle, Shotgun, Home Firearms Safety, Refuse to Be a Victim and Personal Protection in the Home
    Full time instructor for Florida Firearms Training
    21 years as USAF Combat Arms Instructor and First Sergeant

  8. #8
    Join Date
    Dec 2012
    Posts
    1,065
    Feedback Score
    0
    Soup sandwich

  9. #9
    Join Date
    Sep 2015
    Posts
    176
    Feedback Score
    1 (100%)
    Thank you for your contribution boys.

  10. #10
    Join Date
    Mar 2012
    Location
    Kansas
    Posts
    9,767
    Feedback Score
    1 (100%)
    Wow, how long you figure it would take someone to take apart their rifle and do the gymnastics?

    I think you should have anticipated the responses you got.

    Here you go:

    Attachment 42459
